Countersunk square-neck plough bolt M16x80 (grade 10.9)
DIN 608

Countersunk square-neck plough bolt M16x80 (grade 10.9)

150 RSD

Cash on delivery in Serbia

DIN 608 · M16x80 · Grade 10.9 · Head diameter (D): 32 mm · Head and neck height (c): 13,5 mm · Square neck width (v): 16 mm · Head angle (x): 90° · Matching nut spanner size (s): 24 mm · Nut height (m): 13 mm

In stock

Delivery in Serbia: from 700 RSD · Cash on delivery

In-stock parts: delivery in 2–5 business days. The final shipping cost is shown before placing the order.
RELATED PRODUCTS

Application and related products

Other grades of the same bolt

Nuts with the same thread

The standard thread matches. The property class of these nuts is unconfirmed — check the required nut class for the bolt and joint.

Bolts, nuts and washers for assembly: square neck plough bolt

square neck plough bolt

The square neck resists rotation in a matching recess. Compare head dimensions, thread and length.

Names used when searching for this part

This category can be found using these names: square neck plough bolt, square neck plow bolt, countersunk square neck bolt. Compare the part number and mounting pattern before choosing a replacement.

How to identify the correct part

For square neck plough bolt, check the stamped number, machine model, right or left side and hole spacing. A photograph of the part and its mounting helps compare it with the catalogue.

Information to prepare before ordering

Record the part number, quantity and mounting side. Compare dimensions, hole count and shape; a name or brand alone does not establish compatibility.
